Block Plan For 50 Ft. or 100 Ft. Units. Type "A"
Block Plan For 25 Ft. Units. Type "A", Type "B".
Block Plan For 75 Ft. Unit.
Typical Floor Plan For Lot 50 x 100 Ft. Type "B". [Tenement housing plan.]
Typical Floor Plan For Lot 50 x 100 Ft. Type "A". [Tenement housing plan.]
Typical Floor Plan For Lot 25 x 100 Ft. Type "B". [Tenement housing plan.]
Typical Floor Plan For Lot 25 x 100 Ft. Type "A" [Tenement housing plan.]
Typical Floor Plan For Lot 75 x 100 Ft. [Tenement housing plan.]
Plan of Half Block 200 Ft x 400 Ft Showing Tenements 25 ft, 50 ft, and 100 ft Wide
Tenement 50.0 Unit [Tenement housing plan.]
Types of Tenement House Plans As Adapted To Proposed New Tenement Law Requirements
Type of Fifty Foot Tenement House Plan As Adapted To Proposed New Tenement Law Requirements
Type of Seventy-Five Foot Tenement House Plan As Adapted To Proposed New Tenement Law Requirements
[Four tenement housing plans drawn for the Tenement House Commission, State of New York.]
Type Plan of Commerical Tenement Houses
419 East 60th Street. Yellow Taxi Company garage
Beaumont Theatre, Lincoln Center. Balcony Plan. 277 Seats
Beaumont Theatre, Lincoln Center. Orchestra Plan (Main Stage)
River House. Garden Tower Arch, M. Brown apartment.
